A lamella clarifier or inclined plate settler (IPS) is a type of clarifier designed to remove particulates from liquids.

Application

Lamella clarifiers can be used in a range of industries, including mining and metal finishing, as well as to treat groundwater, industrial process water and backwash from sand filters.^[1] Lamella clarifiers are ideal for applications where the solids loading is variable and the solids sizing is fine. They are more common than conventional clarifiers at many industrial sites, due to their smaller footprint.

One specific application is pre-treatment for effluent entering membrane filters. Lamella clarifiers are considered one of the best options for pre-treatment ahead of ultrafiltration. Their all-steel design minimizes the chances that part of the inclined plate will chip off and be carried over into the membrane, especially compared to tube settlers, which are made of plastic. Further, lamella clarifiers may maintain the required water quality to the membrane with or without the use of chemicals. This is a cost-saving measure, both in purchasing chemicals and limiting damage to the membrane, as membranes do not work well with the large particles contained in flocculants and coagulants.

Lamella clarifiers are also used in the municipal wastewater treatment processes. The most common wastewater application for lamella clarifiers is as part of the tertiary treatment stage. Lamella clarifiers can be integrated into the treatment process or stand-alone units can be used to increase the flow through existing water treatment plants. One option for integrating lamella clarifiers into existing plants is for conventional or sludge blanket clarifiers to be upgraded by attaching a bundle of inclined plates or tubes before the overflow in the so-called "clear water zone". This can increase the settling area by two-fold resulting in a decrease in the solids loading in the overflow

Advantange and limit

The main advantage of lamella clarifiers over other clarifying systems is the large effective settling area caused by the use of inclined plates, which improves the operating conditions of the clarifiers in a number of ways. The unit is more compact usually requiring only 65-80 % of the area of clarifiers operating without inclined plates.^[3] Therefore, where site footprint constraints are of concern a lamella clarifier system is preferred. The reduced required area allows the possibility for the clarifiers to be located and operated inside, reducing some of the common problems of algae growth, clogging due to blowing debris accumulation and odour control, that occur when the machinery is outdoors. Operation within an enclosed space also allows for a better control of operating temperature and pressure conditions The inclined plates mean the clarifier can operate with overflow rates 2 to 4 times that of traditional clarifiers which allow a greater influent flow rate and thus a more time efficient clarification process. Lamella clarifiers also offer a simple design without requiring the use of chemicals. They are therefore able to act as pre-treatment for delicate membrane processes. Where necessary flocculants may be added to promote efficiency.

Lamella clarifier performance may be improved by the addition of flocculants and coagulants.^[9] These chemicals optimize the settling process and cause a higher purity of overflow water by ensuring all smaller solids are settled into the sludge underflow.
